DL-1H1A1UCB-H3 Digitalinx Series 4K60 HDMI & USB-C HDBaseT 3.0 Extension Set

DL-1H1A1UCB-H3 Digitalinx Series 4K60 HDMI & USB-C HDBaseT 3.0 Extension Set

Features and Benefits

• HDBaseT3.0 Uncompressed 4K60 & USB Transmitter & Receiver set with accessories
• Uncompressed HDMI 2.0 extension over HDBaseT 3.0 offers resolution support up to 4K60 4:4:4 up to 100m, control, and USB2.0 with isochronous data support for cameras and other USB peripherals over Cat6A U/FTP or above cabling
• Extends 1Gb ethernet between TX & RX and also injects 1Gb ethernet into USB-C for true single cable connectivity
• HDMI / USB-C auto switching based on video sense or 5V detection
• USB-C full featured passes AV via ALT-DP, acts as a USB host, and provides up to 100w charging power to the host computer over USB-C
• HDMI 2.0b, HDCP 2.2 18Gbps 4K60 4:4:4 to 100m over Cat6a U/FTP or above
• Supports HDR, HDR10+, Dolby Vision LLM, HLG
• Supports USB2.0 High Speed (1) Host (2) Clients on TX, (2) Clients on RX
• Supports Isochronous USB data for maximum camera compatibility
• Audio de-embed on both ends
• Built in pattern generator from TX or RX to help with testing and troubleshooting

Brand: Liberty AV Solutions. Product family: INTELIX.

Product Documents

• DL-1H1A1UCB-H3_Owners_Manual
