DL-HD70-H3 Digitalinx Series HDMI 2.0 4K60 Uncompressed 70m Extension Set

DL-HD70-H3 Digitalinx Series HDMI 2.0 4K60 Uncompressed 70m Extension Set

Features and Benefits

• Signal Extension: Transmit 4K60 4:4:4 and all HDR formats including Dolby Vision and HDR10, IR, & RS232 up to 40m and transmit resolutions 4K30 or below up to 70m over a single Cat6A U/FTP or above cable
• Audio Return: De-embed analog or digital audio on the transmitter from the receiver audio in or HDMI
• Flexible Power: Single power supply can be applied at the transmitter or receiver
• HDBaseT 3.0 Technology: Utilizing the latest HDBaseT 3.0 technology, the only technology capable of transmitting uncompressed & flawless HDMI 2.0 and HDR signals, DL-HD70-H3 delivers the exact performance of direct HDMI cable connection
• Pattern Generator Built in: Built in test pattern generator with both HDCP compliant and non-compliant signals for easy testing without the need of a source
• High / Low Bandwidth Mode Selection: Default High bandwidth mode extends fully uncompressed signals. When lower grade cabling such as Cat5e or 6 must be used, or longer distances of 4K60 are required, low bandwidth mode can be used engaging visually lossless compression
• EDID Management: Built in EDID management
• HDCP Compliant: HDCP2.3, 2.2, 1.4 compliant
• For reliable, full featured performance, and to support all uncompressed resolutions / capabilities of all HDBaseT 3.0 devices, shielded Cat6A U/FTP or above must be used.
• TAA Compliant

Brand: Liberty AV Solutions. Product family: INTELIX.
